TECHNICAL DETAILS
- Length X Width X Height1940×825×1075mm
- Wheelbase1370mm
- Seat height820mm
- Fuel capacity13L
- Curb weight149kg
- Ground clearance175mm
- Trail95mm
- Engine typeLiquid-cooled, twin cylinders, DOHC
- Displacement322cc
- Bore x stroke68.0×44.2mm
- Compression ratio11.2:1
- Max. power29.5kW/11000rpm
- Max. torque29N·m/9000rpm
- Fuel supplyEFI
- Max. speed170km/h
- Frame typeDiamond shape, dual-wing beam
- Front suspensionΦ41mm upside down front fork, travel 142mm
- Rear suspensionMonotube shock, travel 57mm
- Front brake320mm, disc, 4-piston opposed calliper/ABS
- Rear brake240mm, disc, 2-piston calliper/ABS
- Front tire 110/70R17
- Rear tire150/60R17
- Steering angle39°
- Rake24°
- InstrumentionLCD
