TECHNICAL DETAILS
- Length X Width X Height2200×935×1400mm
- Wheelbase1479mm
- Seat height830mm
- Tank capacity20L
- Curb weight205 kg
- Ground clearance210mm
- Trail105 mm
- Engine typeDual cylinders, vertical, DOHC, liquid-cooled
- Displacement498cc
- Bore x stroke72×61.2mm
- Compression ratio10.6:1
- Max. power35kW/8500rpm
- Max. torque45N·m/7000rpm
- Fuel supplyBOSCH EFI
- Max. speed170km/h
- Frame typeDiamond shape, dual-wing beam
- Front suspensionKYB preload/damping adjustable
- Rear suspensionKYB preload/damping adjustable
- Front brakeDual discs , 2-piston calliper/ABS
- Rear brakesingle disc, single piston calliper/ABS
- Front tire 110/80R19
- Rear tire150/70R17
- Steering angle35°
- Rake25.5°
- InstrumentionTFT
