TECHNICAL DETAILS
- Length X Width X Height2110×895×1145mm
- Wheelbase1440mm
- Seat height790mm
- Tank capacity18L
- Curb weight194kg
- Ground clearance180mm
- Trail105mm
- Engine typeTwin-cylinder, vertical, DOHC, liquid-cooled
- Displacement498.4cc
- Bore x stroke72×61.2mm
- Compression ratio10.6:1
- Max. power35kW/8500rpm
- Max. torque45N·m/7000rpm
- Fuel supplyBOSCH EFI
- Max. speed170km/h
- Frame typeDiamond shape, dual-wing beam
- Front suspensionφ41mm preload inverted adjustable KYB
- Rear suspensionMonoshock preload adjustable KYB
- Front brakeDual floating discs , 2-piston calliper/ABS
- Rear brakeSingle disc, 1-piston calliper/ABS
- Front tire110/80 R18
- Rear tire160/60 R17
- Steering angle38°
- Rake25.5°
- InstrumentionTFT
